TAG Pipe Rack Rollers & Launchers

Heavy Duty Beam Clamp & Rigging Rollers





TAG Pipe Rack Rollers & Launchers

Features and Advantages

  • Eight configurations from
  • 2,500lbs to 10,000lbs capacity
  • Two sizes from 2—48" pipe diameters
  • Urethane wheels with sealed bearings
  • Easy replace wheels bolt off and on in minutes
  • Charges from rack roller to pipe launcher in minutes
  • Comes ready to use on Stainless Steel





Pipe Rack Rollers & Launchers Options

PART NO. DESCRIPTION PIPE SIZE (MM / INCH) LOAD CAPACITY (KG / LBS)
2110 Beam Clamp Pipe Roller 50—510mm / 2—20" 1135kg / 2,500lbs
2110HD Heavy Duty Beam Clamp Pipe Roller 50—510mm / 2—20" 3410kg / 7,500lbs
2115 Pipe Launcher Stand 50—510mm / 2—20" 1135kg / 2,500lbs
2115HD Heavy Duty Pipe Launcher Stand 50—510mm / 2—20" 3410kg / 7,500lbs
2125 Beam Clamp Pipe Roller 100—1220mm / 4—48" 2270kg / 5,000lbs
2125HD Heavy Duty Beam Clamp Pipe Roller 100—1220mm / 4—48" 4545kg / 10,000lbs
2126 Pipe Launcher Stand 100—1220mm / 4—48" 2270kg / 5,000lbs
2126HD Heavy Duty Pipe Launcher Stand 100—1220mm / 4—48" 4545kg / 10,000lbs
